Trapezoidal 19-1000 Roof Liner Range

Our EC 19-167-1000 Liner 2 profile is used as the internal finish of our Elite 1 Roof System solution.

The profile is available in Bright White Polyester-coated steel material, with a nominal gauge of 0.4mm.

EC 19-167-1000 Liner 2 profile is supplied in 0.4mm steel material
This profile can be crimp curved depending on project requirements. Contact the Technical Team for relevant parameters
This profile can also be naturally concave or convex curved to a minimum radius of 35 metres

Order a profile sample Expert Help Starts Here

Technical Information

The Trapezoidal 19-1000 Roof Liner Range features a profile depth of 19mm, a cover width of 1000mm, and is designed for versatile roofing applications. Key parameters include crimped curve availability, minimum and maximum sheet lengths, and profile weight.

Product Parameters

See table below.

Product Parameters for EC 19-167-1000 Liner 2
Parameter	Value
Cover Width Nominal (mm)	1000
Profile Depth / Height (mm)	19
Profile Pitch (mm)	167
Critical Leg (mm)	18
Runout Leg Minimum (mm)	9
On-site Rolling Availability	N/A
Natural Self Curve Min Radii Concave (m)	35
Natural Self Curve Min Radii Convex (m)	35
Smooth Curve Availability	N/A
Crimped Curve Availability	Yes
Crimped Curve Minimum Sheet Length (m)	0.60
Crimped Curve Maximum Sheet Length (m)	6.50
Crimped Curve Minimum Internal Radii	0.35
Crimped Curve Minimum Sheet Straight Leg (m)	0.30
Profile Weight (kg/m²)	0.4mm: 3.53

Tested Performance

The exposed face coating of the EC 19-167-1000 Liner 2 profile meets BROOF(T4) classification to BS EN 13501-5:2016 by Commission Decision 2000/553/EC.

Coatings

A variety of coating types and finishes are available for the EC 19-167-1000 Liner 2 profile, typically specified in white to give a clean internal finish to the roof construction. Contact our Technical Team for further information regarding these options.
